S1TT30 – Technical Manual

Version: 1.0
Revision Date: 19/10/2025

S1TT30 Station

1. Introduction​

The S1TT30 Station is a smart power bank rental system designed for high-traffic environments like airports, malls, and train stations.

It features:

  • A 27-inch touchscreen with vibrant display
  • 40 power bank slots (5 rows of 8 compartments)
  • Automated locking/unlocking
  • Cloud connectivity for monitoring and remote management

2. Key Features​

  • Display: 27-inch touchscreen with vibrant color display
  • Slots: 40 (5 rows × 8 compartments)
  • Smart Locking System: Solenoid-based
  • Connectivity: Ethernet, Wi-Fi & 4G/LTE
  • Upgradable Firmware
  • Power Supply: 220V industrial-grade adapters
  • Cloud Management
  • Modern Design: Sleek, freestanding kiosk with clean aesthetics

3. Typical Applications​

  • Airports, shopping malls, train stations
  • Events & exhibitions
  • Urban smart city projects

4. Technical Specifications​

Physical​

  • Dimensions: 180×60 cm (tall, slender rectangular structure)
  • Weight: 50 kg
  • Material: Metal structure, folded and painted
  • Design: Freestanding kiosk with tapered side profile
  • Base: Rectangular base wider than main body for stability

Power Bank Management​

  • Slots: 40 (5 rows of 8 compartments)
  • Lock System: Solenoid + spring release
  • Control Board: Tomorrow Tech s.r.l.
  • Microcontroller: STM32 @ 48 MHz

User Interface​

  • Interactive App: Rental & Return

Connectivity​

  • Embedded Computer: Raspberry Pi
  • Data: Wi-Fi & USB 4G dongle
  • Cloud sync: Remote management

Power​

  • Input Voltage: 220V
  • Consumption: 240 Wh
  • Certified Industrial Adapters

Operating Environment​

  • Temperature: 0°C to 50°C
  • Humidity: Up to 90% (non-condensing)
  • MTBF: 500,000 hours

5. Operating Logic​

For detailed information about the rental and return processes, please refer to the dedicated Integration section which covers all operational workflows, payment processing, and system integration requirements.

6. Compliance & Certifications​

Go to certification documentation to see all available certifications of the device.
